Overview
Extreme design for perfect strength training! The newest line of Movement bodybuilding equipment, which combines the most advanced biomechanics with practical solutions for adjustments and use. The result? More efficient and safe training in a contemporary environment.
The line EDGE+ was awarded the if design award – germany 2015, the world design oscar, as a reference in the fitness and leisure category.
Perfect biomechanics, for a much more efficient workout. Guarantee of comfort and safety. The models unite convergence/divergence and unilateral movements, simulating movement in a natural way for superior results.
The line of equipment for strength training has aesthetic and functional differentials for different public profiles.
The necessary adjustments parameters to start the exercise are visible before entering the equipment, with minimal amount and low difficulty, facilitating the use for users with little experience. Adjustments located in the user's preferred zone performed from the exercise position.
EDGE+ package: Stretch / squeeze port; Heavy cargo with a weight of 5kg; Fractionation with step loader; Soft touch selector; Center scoreboard.
Available in versions: Smoke fairing; Translucent fairing; No fairing.
Technical Specifications
LINE | Edge + |
LENGTH (CM) | 192,6 |
WIDTH (CM) | 105,6 |
HEIGHT (CM) | 170,6 |
OCCUPIED AREA (M²) | 2,03 |
EQUIPMENT WEIGHT (KG) | 316 |
WEIGHT BATTERY (KG) | 115 |
MAXIMUM LOAD (KG) | 117,5 |
WEIGHT PLATE (KG) | 5 |
LOAD INCREASE (KG) | 2,5 |
REPEAT COUNTER | Yes |
STRUCTURE | Steel |
CHASSIS THICKNESS (MM) | 3,00 – 6,00 |
TOWER THICKNESS (MM) | 3,00 – 8,00 |
PAINTING | Surface treatment with 9 baths. Electrostatic powder coating, medium thickness, with two curing stages. |
WELD | MIG |
UPHOLSTERY MATERIAL | Injected polyurethane foam with controlled density |
UPHOLSTERY COATING | Eco-leather and reinforced stitching |
STREAMING | Steel cable w/ nylon thermoplastic protection |
CABLE DIAMETER (MM) | 5 |
SHOCK ABSORBER AT THE BASE OF THE TOWER | Yes |
FAIRED TOWER | Yes |
FAIRED PULLEYS | No |
WEIGHT SELECTOR PINS (FLUTE) | Magnetic, with safety cable and rubberized plastic finish |
INSTRUCTION STICKER (PLACARD) | Located in the tower, with instructions for use and recruited muscles |
BOTTLE/OBJECT SUPPORT | Yes |
COLOR OPTIONS | No |
FAIRING OPTIONS | No fairing / Clear fairing / Smoked fairing |
WARRANTY | Up to 3 years – *Refer to the equipment Instruction Manual.* |
Review
Ref .: 050101000900040661
Adductor/Abductor Edge+
